Semi-Integrated Solar Street Lights with Separate Solar Panels
A semi-integrated solar street light uses an independent solar panel and a lamp head that contains the LED light source, LiFePO4 battery and controller. The separate panel can be oriented toward available sunlight while the lamp head remains positioned for road illumination.
NEWSKYPOWER offers X1, MJ-XJ9 and NF series for residential roads, communities, parks, parking areas and commercial or municipal projects. Selection should be based on the required lighting level, mounting height, control mode, solar-panel capacity and local site conditions.
Compare X1, MJ-XJ9 and NF Semi-Integrated Series
X1 and XJ use nominal model-power labels, while NF is specified by rated LED power. Compare luminous output, solar-panel capacity, battery energy and site requirements before selecting a configuration.
| Series | Output reference | Solar panel | Battery | Typical fit |
|---|---|---|---|---|
| X1 | Nominal model labels: 400W / 600W / 1000W / 1200W; luminous flux: 4800 / 5600 / 8800 / 10800 lm | Separate mono panel: 45 / 50 / 70 / 110W | LiFePO4: 3.2V, 40 / 50 / 70 / 93Ah | Residential roads, communities and outdoor areas |
| XJ (MJ-XJ9) | Nominal model labels: 200W–800W; luminous flux: 1800–5500 lm | Separate mono panel: 30–80W | LiFePO4: 3.2V, 20–75Ah | Streets, communities and parks |
| NF | Rated LED power: 30W–80W | Separate mono panel: 80W–150W | LiFePO4: 12.8V, 24–42Ah | Engineering roads, parking areas and municipal projects |
X1-400W, X1-600W, X1-1000W and X1-1200W are nominal model labels, with luminous output of 4800, 5600, 8800 and 10800 lm respectively. The series combines a separate mono solar panel, LiFePO4 battery and die-cast aluminum housing. Panel options range from 45W to 110W, with 3.2V battery capacities from 40Ah to 93Ah according to the model.
MJ-XJ9 includes MJ-XJ902, MJ-XJ903, MJ-XJ904, MJ-XJ905, MJ-XJ906 and MJ-XJ9-S5500Pro, with nominal model labels from 200W to 800W. The series uses a separate adjustable mono solar panel, LiFePO4 battery, die-cast aluminum housing, radar sensing, remote control and IP65 protection.
NF-30W, NF-40W, NF-60W and NF-80W are rated-power models for road and project lighting. Configurations use 80W–150W mono solar panels, 12.8V 24Ah–42Ah LiFePO4 batteries, MPPT control, die-cast aluminum housings and IP65 protection. Constant-lighting and optional motion-sensor versions are available for different operating schedules.
Newskypower Semi Integrated Solar Street Light
The panel can be oriented toward available sunlight without changing the lamp-head angle. Panel capacity and mounting details vary by series and model.
The LED module, LiFePO4 battery and controller are housed in the lamp head, reducing the number of separately mounted system components.
Battery capacity is matched to the selected solar panel, operating schedule and expected backup requirement. Final capacity should be confirmed for the project location.
Automatic night operation is available across the range. Remote control, radar sensing, MPPT charging and dimming functions vary by model.
How a Semi-Integrated Solar Street Light Works
The solar panel is installed separately from the lamp head and connected with the supplied cable. The lamp head combines the LED module, LiFePO4 battery and controller. This structure keeps installation simpler than a fully split system while giving the panel more freedom of orientation than an all-in-one fixture.
Adjustable Solar Panel for Site Orientation
The independent panel can be positioned toward the strongest available sunlight instead of following the lamp-head angle. Confirm the panel direction, tilt, cable route and shading conditions during project planning. The required panel size depends on the selected series and model.
Model-Specific Light Output and Optical Control
X1 and MJ-XJ9 use nominal model-power labels, while NF is specified by rated 30W to 80W output. Compare actual lumen output, mounting height, road width and spacing rather than selecting a model from the power label alone. Optical lenses help direct light toward the target road or outdoor area.
LiFePO4 Battery and Intelligent Control
The three series use LiFePO4 battery configurations matched to their solar panels and control systems. Dusk-to-dawn operation is available across the range. Remote control, radar sensing, MPPT charging and dimming functions vary by model, so the required operating mode should be stated in the inquiry.
Die-Cast Aluminum Housing and Outdoor Protection
Die-cast aluminum lamp housings support heat dissipation and outdoor durability. Confirm the protection rating, mounting arrangement and selected configuration against the destination climate and installation environment.
Installation and Project Applications
Semi-integrated models can serve residential roads, communities, parks, parking areas, campuses and municipal projects. For a reliable recommendation, provide the road width, pole height, spacing, daily lighting schedule, expected rainy-day backup, installation location and project quantity.
Semi-Integrated Solar Street Light Projects and Installations
- Project Gallery
Related Solar Street Light Solutions
Information Needed for a Semi-Integrated Solar Street Light Quote
To recommend a suitable series and configuration, please include:
- Country, city and installation environment.
- Road or area width, pole height and pole spacing.
- Required operating hours and dimming schedule.
- Expected backup during cloudy or rainy weather.
- Motion-sensor, remote-control or constant-lighting preference.
- Required quantity, target delivery date and destination port.
- Any drawing, tender specification or local project standard.
A semi-integrated solar street light has a separate solar panel and a lamp head that integrates the LED module, battery and controller. The panel can be oriented for solar exposure while the lamp head is aimed for road illumination.
The two terms are often used for the same two-part architecture: one separate solar panel and one lamp head containing the other main components. Product naming varies by manufacturer and market, so the component layout should be checked when comparing quotations.
An all-in-one unit places the panel, battery, controller and LED light in one fixture. A semi-integrated model separates the solar panel, allowing the panel direction and tilt to be adjusted independently from the lamp head.
A fully split system normally installs the panel, battery box, controller and luminaire as separate components. A semi-integrated system keeps the battery and controller inside the lamp head, so fewer components need separate mounting.
Choose according to the road width, pole height, required lighting level, control mode, backup requirement and project budget. X1 and MJ-XJ9 cover broad commercial model ranges, while NF provides rated 30W–80W engineering configurations with MPPT control.
Yes. These semi-integrated systems use a separate panel that can be positioned for local sunlight conditions. The mounting bracket, tilt range and installation direction should be confirmed for the selected model.
Control functions vary by configuration. Request the selected X1 or XJ operating modes, remote-control functions and any motion-sensor option in the quotation. NF uses MPPT control and offers an optional motion-sensor configuration.
In this semi-integrated architecture, the LiFePO4 battery and controller are housed inside the lamp head. The solar panel is installed separately and connected by cable.
Provide the installation location, road or area width, pole height, pole spacing, lighting hours, rainy-day backup requirement and any local wind, temperature or project-standard requirements.
Send the project quantity, preferred series if known, required lighting schedule, installation dimensions, destination country or port and any drawing or tender specification. NEWSKYPOWER can then confirm the model, panel, battery, controller and packing configuration.
